CE22 Rotary Switch voicings. Need some answers

[DogPhishHead]

I've found a nice, older CE22 with Dragon I pups and the guitar has a rotary switch. From all I've read so far, can I assume this knob does NOT get the two humbuckers in series ? It seems the three "middle positions" on the knob are variations of split coils and parallel or series circuiting of those.

Am I correct or got it all wrong.

Also - you the Dragon I's get a passable strat "quack" tone. I've got zero knowledge of the older PRS pups.



[toothace]

This'll help...



[jeffgoobs]

Dragon 1s are awesome, man. Yes, they definitely give a great spanky tone. You don't see them around too much on their own; they're fairy sought-after since people tend to leave them in the guitar (which is telling in and of itself.)



[AP515]

I have one on all mahogany. Best tone I own.
